Description:

The Spartan RZ-XD is a premium residential zero-turn mower designed for homeowners who demand power, durability, and comfort. This mower is a step above the RZ Series, offering enhanced performance features and rugged construction for a smoother, more efficient mowing experience. With larger tires, a robust transmission, and a comfortable suspension seat, the RZ-XD is built to handle larger residential properties with ease.

Features:

• Heavy-Duty Frame – Reinforced tubular steel frame for strength and longevity.
• Enhanced Transmission – Equipped with a Parker HTE-10CC commercial-grade transmission for superior performance and control.
• Premium Suspension Seat – Designed for ultimate comfort, reducing fatigue on longer mowing jobs.
• Larger Tires for Smoother Ride – 13” front tires and 24” Reaper rear drive tires offer increased traction and stability.
• Precision Cutting Deck – Deep deck design with adjustable cutting heights for a professional-quality cut every time.
• User-Friendly Controls – Magnetic pin height adjustment, foot-operated deck lift, and automatic parking brake for effortless operation.

Specifications:

Engine

• Engine Model: Kawasaki® FX730
• Horsepower: 24 HP
• Fuel Capacity: 9.5 Gallons

Drive Line

• Hydraulic Drive System: Parker® HTE Transaxles (10cc Drive Motors)
• Torque Output:
• Continuous: 262 ft-lb
• Maximum: 406 ft-lb
• Hydraulic Maintenance Interval: 1,000 Hours Between Oil Changes
• Front Tires: 13" Bias Ply
• Rear Tires: 24″ Reaper
• Wheel Type: Steel
• Speed:
• Forward: Up to 9 mph
• Reverse: Up to 5 mph

Cutting Deck

• Deck Size: 60″
• Deck Type: Reinforced 7-Gauge Full-Floating Fabricated Steel
• Deck Depth: 5″
• Deck Lift: Foot Operated with Shock Assist
• Cutting Height Range: 1″ – 5″
• Height Adjustments: 15 Positions via Magnetic Pin Adjustment
• Blade Spindles: Cast Aluminum, Sealed (Maintenance-Free)
• Parking Brake: Foot Operated

Frame & Features

• Frame Construction: 1.5″ x 3″ Powder-Coated, Fusion-Bonded Solid Steel
• Seat Type: Dymetrol® Suspension Seat with 360° Floating Platform
• Steering Levers: Adjustable Up/Down
• Ignition: Key Switch
• Auxiliary Power: 12V Accessory Outlet
• Storage:
• Phone Holder
• Cup Holder
• Deep Storage Tray
• Hitch: Not Applicable
• ROPS: Folding Roll-Over Protection System

Measurements

• Width: 62.5″
• Length: 84″
• Height:
• 75″ with ROPS Up
• 54″ with ROPS Folded Down
• Weight: 907 – 1,095 lbs
