Description:

The Spartan RZ-HD is designed for homeowners who need commercial-grade durability in a residential mower. With a reinforced frame, premium cutting deck, and enhanced comfort features, the RZ-HD delivers exceptional performance and control. Whether you're tackling rough terrain or maintaining a large property, this mower is built to handle it all.

Features:

• Heavy-Duty Construction – Built with a 3" x 1.5" HD fusion-welded tubular steel frame for unmatched durability and stability.
• Advanced XTF Deck System – Designed for optimal airflow and seasonal adaptability, ensuring a clean, precise cut every time.
• Smooth & Responsive Steering – Equipped with Parker HTE 10cc transaxles, providing superior torque and smooth handling.
• Enhanced Operator Comfort – Features a foot-controlled parking brake, anti-slip mat, and adjustable steering levers for an ergonomic mowing experience.
• Commercial-Grade Deck – Built from 7-gauge steel, offering long-lasting performance and durability.
• Increased Traction & Stability – Larger tires and improved weight distribution provide better control on inclines up to 15 degrees.

Specifications:

Engine

• Engine Options:
• Kawasaki® FR691V – 24 HP
• Briggs & Stratton® CXi – 27 HP
• Fuel Capacity: 9.5 Gallons

Drive Line

• Hydraulic Drive System: Parker® HTE Transaxles (10cc Drive Motors)
• Torque Output:
• Continuous: 262 ft-lb
• Maximum: 406 ft-lb
• Hydraulic Maintenance Interval: 1,000 Hours Between Oil Changes
• Front Tires: 13x6.5-R6 Smooth Tread (Optional Radial Upgrade)
• Rear Tires: 23″ Reapers
• Wheel Type: Steel
• Speed:
• Forward: Up to 9 mph
• Reverse: Up to 5 mph

Cutting Deck

• Deck Size: 60″
• Deck Type: Reinforced 7-Gauge Full-Floating Deck
• Deck Depth: 5″
• Deck Lift: Foot Operated with Shock Assist
• Cut Height Range: 1″ – 5″ with 15 Adjustable Positions (Magnetic Pin System)
• Blade Spindles: Cast Aluminum, Maintenance-Free (Sealed Bearings)
• Parking Brake: Foot Operated

Chassis & Frame

• Frame: 1.5″ x 3″ Fusion-Bonded Powder-Coated Solid Steel Bridge Frame
• Seat: 360° Floating Suspension Seat Platform
• Steering Levers: Adjustable Up and Down
• Ignition: Key Switch
• Auxiliary Power: 12V Outlet
• Storage: Cup Holder, Phone Slot, Deep Storage Tray
• Hitch: Not Applicable
• ROPS: Folding – 75″ Height (Up), 54″ Height (Down)

Measurements

• Overall Width: 62.5″
• Overall Length: 84″
• Height:
• 75″ with ROPS Up
• 54″ with ROPS Folded Down
• Weight: 907 – 1,095 lbs
