Description:

Features:

• Versa Guard Personalized Control Panels
• 1 1/2" x 3" Tubular Welded Frame
• Magnetic Pin Height Adjustment
• Key Switch Panel
• Foot Operated Deck Lift
• 5" Deck Height
• 18,500 FPM Blade Tip Speed
• Protective Side Deck Trim
• GT Trac Stabilization
• Upgraded Spindles
• 12V Outlet
• Large Cup Holder
• Phone Holder in Console
• Storage Tray in Console
• Foot Operated Parking Brake
• Folding ROPS
• 7-gauge XTF Deck
• 3-year Warranty

Specifications:

Engine

• Engine Name: Kawasaki FR691V
• Horsepower: 24 / 27 HP
• Fuel Capacity: 9.5 gal

Drive Line

• Hydraulic Drive System: Parker HTE Transaxles – 10cc Drive Motors
• Hydraulic Drive Torque:
• Continuous Torque: 262 ft-lbs
• Maximum Torque: 406 ft-lbs
• Hydraulic Maintenance Interval: 1,000 hours between oil changes
• Front Tires: 13x6.5-R6 Smooth Tread (Optional: Radial Upgrade)
• Rear Drive Tires: 23" Reapers
• Wheel Type: Steel
• Speed (Forward/Reverse):
• Forward: Up to 9 mph
• Reverse: Up to 5 mph

Cutting Deck

• Deck Size: 48"
• Deck Depth: 5" Deep, Reinforced 7-Gauge Full-Floating Deck
• Deck Lift System: Foot Operated with Shock Assist
• Deck Height Adjustment: Magnetic Pin Height Adjustment
• Cutting Height Range: 1" – 5"
• Cutting Height Steps: 15 Positions
• Blade Spindles: Cast Aluminum, Maintenance-Free Sealed Bearings
• Parking Brake: Foot Operated

Features

• Acreage Rating: 2+ Acres
• Seat: 360° Floating Seat Platform
• Steering Levers: Adjustable Up and Down
• Ignition: Key Switch
• Auxiliary Power: 12V Outlet
• Storage: Phone Holder, Cup Holder, Deep Storage Tray
• Hitch: Not Applicable
• Control Panel (LCD/LED): Not Applicable

Frame

• Material: 1.5" x 3" Powder-Coated, Fusion-Bonded Solid Steel Bridge Frame

Dimensions / Weight

• Width (with 48” Deck): 49.5"
• Length: 84"
• Height:
• ROPS Up: 75"
• ROPS Down: 54"
• Weight Range: 907 – 1,095 lbs

Warranty

• Full Warranty: 3 Years / 400 Hours (120-Day Belt Coverage)
• Engine Warranty: 3 Years
• Deck Warranty: Lifetime (Leading Edge Only)
• Hydraulic Drive Warranty: 3 Years / 750 Hours
• Control Panel Warranty: Not Applicable
