Description:

The Spartan KGZ-XD is the ultimate zero-turn mower for those who demand maximum power, durability, and efficiency. Built for commercial landscapers and serious property owners, this mower features cutting-edge technology, industry-leading comfort, and heavy-duty construction to handle the toughest mowing conditions with ease.

Features:

• Unmatched Engine Power – Equipped with a 40 HP Vanguard Big Block EFI/ETC engine with Oil Guard System, providing extended engine life and fuel efficiency.
• Heavy-Duty Transmission – Features Parker HTG 16cc transaxles, ensuring seamless power transfer and superior handling.
• Expansive Fuel Capacity – A massive 17-gallon fuel tank allows for longer mowing sessions with fewer refueling stops.
• Premium Cutting Deck – Available in 61” and 72” deck sizes, the 6” deep, 7-gauge steel floating deck delivers a professional-grade cut every time.
• High Blade Tip Speed – With 18,500 FPM blade tip speed, expect clean, precise cuts with optimal grass dispersion.
• Reinforced Heavy-Duty Frame – A 1 1/2" x 3" tubular welded frame ensures unmatched strength and durability.
• Advanced Suspension System – Features rear spring suspension, TecsPak® under-seat support, and a 360-degree seat plate, reducing vibration and enhancing comfort.
• Michelin Tweels® for Superior Traction – Equipped with 13x6.5-R6 front and 24x14-R12 rear Michelin Tweels®, eliminating flat tire worries while providing optimal grip.
• User-Friendly Controls – Includes a customizable key switch panel, magnetic pin height adjustment, foot-operated deck lift, and a full-beam LED light bar for convenience and visibility in all conditions.

Specifications:

Engine

• Engine Model: Vanguard® Big Block EFI/ETC with Oil Guard
• Horsepower: 40 HP
• Fuel Capacity: 17 Gallons
• Ignition Type: Keyless, Personal Code Activated

Drive Line

• Hydraulic Drive: Parker® HTG Transaxles with 16cc Drive Motors
• Torque Output:
• Continuous: 498 ft-lb
• Maximum: 587 ft-lb
• Hydraulic Maintenance Interval: 1,000 Hours Between Oil Changes
• Front Tires: 13x6.5-R6 Michelin® Tweels
• Drive Tires: 24x14-R12 Michelin® Tweels
• Wheel Type: Michelin® Tweels
• Speed:
• Forward: Up to 15 mph
• Reverse: Up to 6 mph

Cutting Deck

• Available Deck Sizes: 61″ & 72″
• Deck Type: Reinforced 7-Gauge Full-Floating Fabricated Steel
• Deck Depth: 6″
• Deck Lift: Foot Operated with Shock Assist
• Cutting Height Range: 1″ – 5″
• Height Adjustments: 15 Positions (Magnetic Pin Height Adjustment)
• Blade Spindles: Cast Aluminum, Sealed (Maintenance-Free)
• Parking Brake: Foot Operated

Frame & Features

• Frame: 1.5″ x 3″ Powder-Coated, Fusion-Bonded Solid Steel Bridge Frame
• Seat: Supreme Custom Blackout Seat with Adjustable TecsPak® Elastomer Supports and 360° Floating Seat Platform
• Steering Levers:
• Soft-Touch Knobs (Adjustable Forward/Back)
• Height Adjustable
• Control Panel:
• LCD Display with:
• Engine Hour Meter
• Mower Deck Hour Meter
• Tachometer
• Low-Level Warning Volt Meter
• Oil Change Countdown
• Fault Codes
• LED Warning Indicators for:
• Parking Brake
• Drive Levers
• PTO
• Operator Presence
• Battery Voltage
• Oil Pressure
• Auxiliary Power: 12V Accessory Outlet
• Storage: Cup Holder, Phone Holder, Deep Storage Tray
• Hitch: 2″ Rear Receiver Standard
• ROPS: Folding Roll-Over Protection System

Measurements

• Width:
• 61″ Deck: 62.5″
• 72″ Deck: 73.5″
• Length: 84″
• Height:
• 75″ with ROPS Up
• 54″ with ROPS Folded Down
• Weight: 1,310 lbs
