Description:

Features:

• Versa Guard Personalized Control Panels
• 1 1/2" x 3" Tubular Welded Frame
• Magnetic Pin Height Adjustment
• Key Switch Panel
• Foot Operated Deck Lift
• Parker HTG 16cc Transmission
• 17 gal Fuel Capacity
• 6" Deck Height
• 18,500 FPM Blade Tip Speed
• Protective Side Deck Trim
• GT Trac Stabilization
• Upgraded Spindles
• 12V Outlet
• Large Cup Holder
• Phone Holder in Console
• Storage Tray in Console
• Foot Operated Parking Brake
• Ultra-Premium Dymetrol® Adjustable 3" Travel Seat
• Folding ROPS
• 7-gauge XTF Deck
• 2" Receiver Hitch
• TecsPak® Under Seat
• Rear Spring Suspension
• Front Suspension Forks
• Oil Guard System
• Dual Exhaust
• Spoiler Basket
• Oversized Electric Clutch
• Multi-Function Keypad with Soft Start
• 3-year Warranty
• 360-degree Seat Plate
• Adjustable Steering Arms
• Full Beam LED Light Bar

Specifications:

Engine

• Engine Name: Vanguard Big Block EFI/ETC with Oil Guard
• Horsepower: 40 HP
• Fuel Capacity: 17 Gallons

Drive Line

• Hydraulic Drive: Parker HTG Transaxles - 16cc Drive Motors
• Hydraulic Drive Torque: Continuous - 498 ft-lb | Max Torque - 587 ft-lb
• Hydraulic Drive Maintenance: 1000 Hours Between Oil Changes
• Front Tires: 13x6.5-R6 Michelin Tweels®
• Drive Tires: 24x14-R12 Michelin Tweels®
• Wheel Type: Michelin Tweels®
• Speed (F/R): Forward - Up to 15mph | Reverse - Up to 6mph

Features

• Acreage: 5+
• Seat: Supreme Custom Blackout Seat - Adjustable TecsPak Elastomer supports - 360 degree floating seat platform
• Steering Levers: Soft-Touch Knobs to Adjust Forward and Back. Adjustable Up and Down
• Control Panel LCD Display: Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time Between Oil Change Countdown - Fault Codes
• Control Panel LED Warning Indicators: Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI
• Ignition: Keyless, Personal Code activated
• Auxiliary Power: 12v Outlet
• Storage: Phone Holder, Cup Holder, and Deep Storage Tray
• Hitch: 2” Rear Receiver Standard

Cutting Deck

• Deck Size: 72"
• Deck Depth: 6" Deep, Reinforced 7 Gauge Full-Floating Deck
• Deck Lift: Foot Operated with Shock Assist
• Deck Adjustment: Magnetic Pin Height Adjustment
• Cut Height: 1" to 5" with 15 Cut Heights
• Blade Spindles: Cast Aluminum, No Maintenance/Sealed Bearings
• Parking Brake: Foot Operated
• Frame: 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame

Measurements

• Width: 72” Deck - 73.5” Wide
• Weight: 1310lbs
• Length: 84”
• Height: 75" with ROPS Up - 54" with Folding ROPS Down

Warranty

• Full Warranty: 2 Year / Unlimited Hour Commercial - 120 Day Belt
• Engine Warranty: 3 Year
• Deck Warranty: Lifetime on Leading Edge
• Hydraulic Drive Warranty: 3 Year / 750 Hour
• Control Panel Warranty: 3 Year
