Description:

Our passion for muscle cars from the late '60s has fueled the design of Spartan Mowers. Mow in style and turn heads with the stealthy profile of a Spartan

Mounted directly to the front of the mower, an LED light bar is great for finishing up at dusk and lighting the way to your trailer or shed. Light bars are standard on Spartan's RZ-HD Blackout, RT-HD, SRT series, KG-XD, and KGZ-XD models.

Features:

• Parker HTJ 12cc Wheel Motors
• 100-300 lb Operator Platform
• Magnetic Pin Height Adjustment
• Quick Change Seat
• Rubber Anti-Scrape Mower Chute
• Lean-In Bolster at Optimal Angle

Specifications:

Engine

• Engine Name: Kawasaki FT730V
• Horsepower: 24 HP
• Fuel Capacity: 12 gal

Drive Line

• Hydraulic Drive System: Parker HTE Transaxles – 10cc Drive Motors
• Hydraulic Drive Torque:
• Continuous Torque: 262 ft-lbs
• Maximum Torque: 406 ft-lbs
• Hydraulic Drive Maintenance Interval: 1,000 hours between oil changes
• Front Tires: 13x6.5-R6 Smooth Tread (Options: Radial Upgrade, No Flats, or Tweels)
• Rear Drive Tires:
• 54" Deck: 24x10.50-R12 Radial
• 61" Deck: 24x12-R12 Radial
• Wheel Type: Steel
• Speed (Forward/Reverse):
• Forward: Up to 9 mph
• Reverse: Up to 5 mph

Cutting Deck

• Deck Sizes Available: 54", 61"
• Deck Depth: 6" Deep, Reinforced 7-Gauge Full-Floating Deck
• Deck Lift System: Foot Operated with Shock Assist
• Deck Height Adjustment: Precision Deck Height Pin System
• Cutting Height Range: 1" – 5"
• Cutting Height Steps: 15 Positions (Dial Adjustable)
• Blade Spindles: Cast Aluminum, Maintenance-Free Sealed Bearings
• Parking Brake: Hand Operated

Features

• Acreage Rating: 4+ Acres
• Seat:
• Smart Ride Technology with Full Suspension Operator Platform
• Reinforced Knee Bolstering
• TecsPak® Elastomer Rollers on Radial Tires
• Optional Fully Adjustable Suspension Seat System
• Steering Levers: Adjustable Speed Stops
• Control Panel (LCD):
• Engine Hour Meter
• Mower Deck Hour Meter
• Tachometer
• Low Level Warning Volt Meter
• Oil Change Countdown
• Fault Code Display
• Control Panel (LED Indicators):
• Parking Brake Set
• Drive Levers
• Operator Present
• PTO
• Battery Voltage (Low/High)
• Low Oil Pressure
• Ignition: Keyless, Personal Code Activation
• Auxiliary Power: 12V Outlet (Located next to Phone Holder)
• Storage: Phone Holder, Cup Holder, Deep Storage Tray
• Hitch: Not Applicable

Frame

• Material: 1.5" x 3" Powder-Coated, Fusion-Bonded Solid Steel Bridge Frame

Dimensions / Weight

• Width:
• 54" Deck: 55.5"
• 61" Deck: 62.5"
• Length: 72.5"
• Height: 49"
• Weight:
• 54" Deck: 1,011 lbs
• 61" Deck: 1,044 lbs

Warranty

• Full Warranty: 2 Years / Unlimited Hours (Commercial Use), 120-Day Belt Coverage
• Engine Warranty: 3 Years
• Deck Warranty: Lifetime (Leading Edge Only)
• Hydraulic Drive Warranty: 3 Years / 750 Hours
• Control Panel Warranty: 3 Years
