Description:

Features:

• Vibration Control Deck System
• Enhanced XTF Deck System
• 4" Deep Deck
• 5 gallon Fuel Tank
• 42" Deck Option for Smaller Spaces
• Versa Guard Personalized Control Panels
• Tuff Torq 300 Series Hydraulic Drive
• 1 1/2" x 3" Tubular Welded Frame
• 3-year Warranty

Specifications:

Engine

• Engine Name: Kawasaki FR691V
• Horsepower: 23HP
• Fuel Capacity: 5 Gallons

Drive Line

• Hydraulic Drive: Tuff Torque 300 Series
• Hydraulic Drive Torque: Continuous - 118 ft-lb | Max Torque - 295 ft-lb
• Hydraulic Drive Maintenance: 200 Hours Between Oil Changes (when heavily used)
• Front Tires: 13x6.5-R6 Smooth Tread
• Drive Tires: 54" - 20x10-10 Turf Armor
• Wheel Type: Steel
• Speed (F/R): Forward - Up to 7.5mph | Reverse - Up to 5mph

Features

• Acreage: 2+
• Seat: Comfortable, Custom Design
• Steering Levers: Adjustable Up and Down
• Control Panel LCD Display: Engine Hour Meter - Mower Deck Hour Meter - Tachometer - Low Level Warning Volt Meter - Time Between Oil Change Countdown - Fault Codes
• Control Panel LED Warning Indicators: Parking Brake Set - Drive Levers - Operator Present - PTO - Low/Hi Battery Volts - Low Oil PSI
• Ignition: Keyless, Personal Code activated
• Auxiliary Power: 12v Outlet
• Storage: Large Cup Holder & Storage Tray
• Hitch: N/A

Cutting Deck

• Deck Size: 54"
• Deck Depth: 4" Deep, Reinforced 7 Gauge Full-Floating Deck
• Deck Lift: Foot Operated with Shock Assist
• Deck Adjustment: Change-On-The-Go Precision Deck Height Dial
• Cut Height: Quick Adjust Dial from 1" to 4.25" with 12 Cut Heights
• Blade Spindles: Cast Aluminum, No Maintenance/Sealed Bearings
• Parking Brake: Foot Operated
• Frame: 1.5" by 3" Powder Coated Fusion-Bonded Solid Steel Bridge Frame

Measurements

• Width: 54” Deck - 55.5” Wide
• Weight: 719lbs
• Length: 81”
• Height: 44”

Warranty

• Full Warranty: 3 Year / 300 Hour - 120 Day Belt Warranty
• Engine Warranty: 3 Year
• Deck Warranty: Lifetime on the leading edge
• Hydraulic Drive Warranty: 3 Year / 200 Hour
• Control Panel Warranty: 3 Year
