Description:

The pristine cut offered by the RhinoAg X Series Roller Mowers is now more accessible than ever. Smaller cutting widths make the X603 and X804 ideal for more compact applications that still need the professional finish the X Series is known for.

With a versatile cutting height up to 5”, these rigid-deck roller mowers get the job done without fuss. The tempered steel blades pivot on high-tensile pivot bush assembly and there are no belts, making maintenance simple.

Features:

• 100% gear driven - no belts
• Reinforced 8-gauge Strenx® 700 MC structural steel deck
• Hardened, tempered spring steel blade carrier
• 3” x ¼” hardened, tempered, ground-edged parallel spring steel blades with 2 ½” overlap
• Sealed internal roller bearings for total protection against moisture, soil, and debris
• Galvanized finish for durability
• PTO Requirement of 50 - 60 HP

Specifications:

DIMENSIONS & CAPACITY

• Cutting Width: 8' (96")
• Transport Width: 8' 2"
• Overall Length: 4' 3"
• Cutting Height: Up to 5"
• Mowing Rate: 6.7 acres/hr @ 7 mph
• Weight: 1,235 lbs

CUTTING SYSTEM

• Blades: 8 × 3” x 1/4” spring steel (hardened, tempered, ground-edged)
• Blade Overlap: 2.5"
• Blade Carrier: 3.25" x 3/8" hardened spring steel
• Rotors: 4
• Blade Tip Speed: 14,764 FPM

DECK CONSTRUCTION

• Material: 8-gauge Strenx® 700MC monocoque (folded)
• Reinforcement: Underside trough in 8-gauge Strenx® 700MC

POWER REQUIREMENTS

• Min. Tractor PTO HP: 50 HP
• PTO Speed: 540 RPM
• Output Shaft: 1.5" (40mm)
• Driveline: CAT 4 - 1 3/8” 6-spline

OTHER FEATURES

• Hitch Type: Lift-Type
• Gearbox Oil: 85W-140 (factory-filled)
