Description:

Rhino rotary tillers offer state-of-the-art design and superior features for unparalleled quality and performance in a number of applications.

The rugged SRM series tillers are ideal for heavy-duty commercial contractor or agricultural uses including sod farms, vegetable farms, and vineyards. Built in 81" and 91" widths, Rhino SRM tillers are available with a single or variable speed gearbox for varying applications. SRM tillers are rated for tractors from 40 to 70 HP and feature a Cat 4 driveline with slip clutch protection and a massive gear rotor drive system running in an enclosed oil bath for dependability in extreme conditions.

Features:

• Rotor Speeds of 185, 208, 235, or 266 RPM
• 4-Speed Gearbox
• CAT 4 Driveline
• Slip-Clutch Protection
• Gear Driven
• Quick-Hitch Compatible
• Sod Farms
• Vegetable Farms
• Vineyards
• Commercial Contractor
• Heavy-Duty Agricultural

Specifications:

General

• Model: SRM91V
• Tilling Width: 91″
• Overall Width: 96″
• Tilling Depth (Max.): 8″
• Tine Rotation: Forward
• Support Stand: Standard

Tractor Requirements

• Hitch Type: CAT 1 & CAT 2, Quick Hitch Compatible (CAT 1 QH)
• Recommended PTO Horsepower: 40 – 70 HP
• PTO Speed: 540 RPM
• Rotor Speeds (at 540 PTO RPM): 185 / 208 / 235 / 266 RPM

Driveline

• Driveline Size: Category 4
• Driveline Protection: Slip Clutch
• Rotor Drive Type: Gear Drive

Tines & Rotor

• Knife Type: “C”-shaped blades
• Number of Knives: 54
• Number of Flanges: 9

Construction

• Housing Thickness: 4 mm
• End Plate Thickness: 8 mm

Dimensions & Weight

• Overall Width: 96″
• Approximate Weight: 992 lbs
