Description:

The perfect option for leveling or grading around the farm or when landscaping is the Rhino MBX Series. These Medium Duty Box Blades offer Rhino durability and strength with their heat-treated scarifier tips, replaceable cutting edges, and heavy-duty triple strap hitches.

Features:

• Available from 5-8' Width
• Replaceable/Reversible Bolted Cutting Edges
• Swinging Rear Tailgate
• CAT 1 Quick-Hitch Compatible
• 55 PTO HP for 4-Wheel Drive or 65 PTO HP for 2-Wheel Drive

Specifications:

Dimensions

• Working Width: 60"
• Overall Width: 61"
• Overall Depth: 27 1/2"
• Overall Height: 34"
• Moldboard Height: 18"
• Box Depth: 21 1/2"

Cutting & Scarifying

• Cutting Edges: 1/2" x 6"
• Scarifier Size: 3/4" x 2 1/2"
• Number of Scarifiers: 6

Hitch Compatibility

• Hitch Type: CAT 1, 2 Quick Hitch compatible

Tractor Compatibility

• Max Tractor HP (2WD): 65 HP
• Max Tractor HP (FWD): 55 HP

Construction

• End Plate Thickness: 3/8"

Weight

• Approximate Weight: 580 lbs
