Description:

The Rhino 4000 “Epic” series rotary cutters boost the horsepower requirement to 60, getting the the ability to cut brush up to 4” in diameter! The stronger gearbox is tested up to 250 horsepower, while the whole unit is protected by a safety chain!

Couple that with slip-clutch protection and hydraulic wing-lift and you’ve got a monster rotary cutter not to be taken lightly!

And NEW to the lineup is our heavy-duty 12' model, the 4125! This flex-wing has the guts of a 4000 Series mower but in a completely redesigned 12' frame. Unique to the 4125 is the independent axle arm suspension. This reduces the stress of heavier material and higher hour workloads - which in turn leaves you with less downtime and maintenance.

With over three years of testing, we are confident this machine will be a staple for the heavy-duty workloads. And just like the 4105 and 4155, this model is available for government bid.

Features:

• 60 Horsepower PTO Requirement
• 250 Horsepower Gearbox (160 HP on 4125 model)
• Chain Guard Safety Deflectors
• 3 Optional Wheel Configurations (2 for 4125 model)

Specifications:

• Dimensions
• Cutting Width: 15'
• Transport Width: 96"
• Transport Height: 80"
• Overall Width: 187"
• Overall Length: 183"
• Cutting Height: 2"–14"
• Cutting & Blade System
• Blade Carrier: Infinity
• Blades: 1/2" x 4" Parallel Lift
• Blade Overlap: 6"
• Cutting Capacity (Diameter): 4 1/2"
• Blade Tip Speed (Center):
• 540 RPM: 16,286 FPM
• 1000 RPM: 16,380 FPM
• Blade Tip Speed (Wing):
• 540 RPM: 16,422 FPM
• 1000 RPM: 15,983 FPM
• Driveline & Gearbox
• PTO Horsepower Required: 60 HP
• Gearbox Ratings (Field Performance):
• Divider: 250 HP
• Center & Wing: 225 HP
• Gearbox Oil: Factory filled with 85W-140
• Output Shaft Diameter: 3"
• Driveline Size (Main): CAT 6 CV
• Driveline Size (Wing): CAT 5
• Driveline Protection: Slip Clutch
• Construction
• Deck Thickness: 7 GA
• Side Skirt: 1/4" AR400
• Military Grade Steel: 1/4" AR400
• Hitch & Adjustments
• Hitch Type: Pull
• Height Adjustment: Hydraulic Cylinder (Self-Leveling)
• Jack Stand: Standard
• Wings & Flexibility
• Wing Lift Hydraulics: Standard
• Wing Flex (Transport): 90° Up / 25° Down
• Wing Flex (Operational): 45° Up / 25° Down
• Safety & Lighting
• Safety Tow Chain: Standard
• LED Light Kit: Standard
• Safety Deflectors: Chain Guards
• Tires & Weight
• Tires & Wheels: RhinoTrax, Foam Filled, Laminated
• Tongue Weight: 1,870 lbs
• Approximate Total Weight: 5,455 lbs
