Description:

With its incredible quality of cut courtesy the AirFX™ deck, commercial-grade transmission, and large drive tires, the ZT5000 is built for professional landscapers who demand the most from their machines, day after day.

The ZT5000 is an ideal fit for landscapers and homeowners who need a solid step up from an entry-level commercial mower.

23.5-hp Kawasaki® FX series engine provides commercial-quality performance and outstanding durability.

The bullnose AirFX™ cutting deck provides a phenomenal quality of cut and even clipping dispersal.

Commercial-grade Hydro-Gear® ZT-3800 transaxles deliver the performance and torque required for all-day mowing.

High-back suspension seat and almond shaped handles provide operator comfort.

 Large 7.8 gallon fuel capacity reduces the time required to stop and refuel.

Features:

• High performance FX series engine
• Featuring the AirFX™ cutting deck
• Commercial grade transmission
• Heavy duty, tubular frame
• Ground speeds of up to 11 mph
• Specifications:

Specifications:

Mower Deck

• Deck Type: AirFX Dual 10-gauge layer top with 3-gauge and 7-gauge brackets throughout
• Cutting Width: 52 in
• Cutting Height: 1.5-4.8 in (38-121 mm)
• Blade Tip Speed: 18,142 ft/min
• Discharge Chute: Flexible Molded Polymer

Engine

• Emissions Tier (EPA): Tier 4
• Engine Model: Kawasaki FX730V Gas Engine
• Displacement: 726 cm³
• Fuel Capacity: 7.8 gal
• Horsepower: 23.5 hp

Performance

• Weight: 995 lb

Transmission

• Transmission Type: Hydro Gear ZT-3800 Hydrostatic
• Pump Displacement: 11 cm³
• Oil Capacity: 4 qt (US liquid)

Electrical

• Clutch Torque: 125 ft·lbf

Frame

• Material: Welded 7-gauge Steel; 1.5- x 2.5-inch Steel Tubing
• Length: 79.8 in

Wheels

• Drive Wheel Size: 24 x 10.5-12
• Front Caster Wheel Size: 13 x 6.5-6
• Caster Arm Attachment: Welded to Frame
