Description:

The lower ground pressure from a TRX track system minimizes damage to soft terrain, reducing spinning and rutting. High traction ensures superior control, especially on slopes, empowering operators to navigate challenging terrains confidently, enhancing efficiency across various landscapes. Depending on the TRX model, you can choose the perfect track for your applications: the all-new commercial-grade TerraFlex™ tracks, all-terrain tracks or turf tracks.

Specifications:

Engine

• Horsepower: 29.5 HP
• Manufacturer: Kawasaki
• Model: FX EFI
• Displacement: 852 cc
• Cylinders: 2
• Air Filter: Multi-Stage Canister
• Fuel Type: Gasoline
• Fuel Capacity: 14 gallons
• Fuel Tank Location: Side-mounted, dual tanks

Drive Line

• Transmission Type: Hydrostatic
• Transmission Manufacturer: Hydro-Gear
• Transmission Model: ZT-4400
• Max Forward Speed: 9 mph
• Front Tire Size: 13 inches

Cutting Deck

• Cutting Width: 61 inches
• Deck Options: Fabricated Steel All-Terrain Deck (AT) or Aero Finish Cut Deck (FC)
• Deck Thickness: Laminated 7 & 7 gauge (AT) / Laminated 10 & 7 gauge (FC)
• Deck Depth: 6" (AT) / 5.5" (FC)
• Cut Height Range: 3" to 7" (AT) / 2.5" to 6" (FC)
• Cutting Height Increments: 1/4 inch
• Number of Blades: 6 for All-Terrain, 3 for Finish Cut
• Blade Speed: 18,500 feet per minute
• Anti-Scalp Wheels: 6 recessed (not included on All-Terrain deck)
• Deck Lift System: Manual
• Clutch Torque: 250 ft-lbs
• Clutch Manufacturer: Warner

Features

• Armrests
• Seat suspension system
• Adjustable lumbar support
• Seat weight adjustment
• Fore and aft seat positioning
• High-back seat with tilt adjustment
• Cup holder
• Integrated fuel gauge
• Folding ROPS (Roll Over Protection Structure)
• TorqFlex™ front suspension
• Soft start clutch engagement
• Keyless push-to-start ignition
• SmarTrac™ Pro Control system

Dimensions & Weight

• Overall Length: 93 inches
• Width (with chute up): 62 inches
• Height (with ROPS up): 79 inches
• Weight: 1,540 lbs

Warranty

• Homeowner / Commercial:
• 3 years engine
• 2 years transmission
• 1 year overall manufacturer coverage
• Rental:
• 3 years engine
• 2 years transmission
